Cylinder Pressure Regulator for Nitrogen up to 20 bar

ewo Cylinder Pressure Regulator Nitrogen

Single stage, cylinder connection on the left side, DIN EN ISO 2503 (formerly DIN EN 585)

Single-stage cylinder pressure regulators are used to reduce compressed, liquefied and dissolved gases from cylinders with a maximum inlet pressure of 200 bar to the desired working pressure, as independently as possible of inlet pressure or withdrawal rate fluctuations. The upstream pressure dependency of single-stage cylinder pressure regulators is approx. 1.5%, so that readjustment is necessary from time to time when the cylinder is emptied.

Cylinder inlet pressure: 200 bar

Adjustment range: 0,5 - 20 bar

Inlet connection (cylinder): W24.3 x 1 1/4" i

Connection outlet: G 1/4 x LW6

Manufacturer Nr.: EWO 120.444

EAN: 4030875105957
